Principal Characteristics

• Construction Material: Fiberglas
• Hull Form: Planning hull – Deep Vee Monohull
• Length (Loa): 12.65 m.
• Beam (B): 3.60 m. (at midship)
• Draft (D): 0.75 m. (full load)
• Height (D): 1.80 m. (at midship)
• Fuel Capacity (approx.): 1700 Lit.
• Watertight Bulkhead: 4
• Cabin Height: 1.85 m.
• Max. Speed (approx.): 45 Mile Per Hour
• Cont. Speed (approx.): 40 Mile Per Hour
• Endurance (approx.): 300 mile
• DWT: 1250 kg
• Accommodations: 12 seat in cabin 4 seat on the aft deck
• Crew: 2 persons
• Environment: Fully operational up to sea state 2
• Class: Dual Class (RINA & Turkish Lloyd)
• Class Notation: 100 / A / 1.1 Y
• Standards: SOLAS 74, IMO, ISO, TSE, NATO STANAGS

Propulsion

• Engine Maker: CATERPILLAR – USA
• Model: 3196 TA – E Rating
• Power: 2 x 492 KW ( 2x 669 HP) @ 2300 rpm
• Gear Box Maker: ZF – Germany / Italy
• Model: IRM 312 TS (Two Speed)
• Reduction: 1:195 – 1 : 1.432
• Drives: ZF Trimax 2200 I
• Propeller: SST; 6 blades; ROLLA

Electrical

• Electrical Rectifier: VICTRON – SKYLLA 220 V AC, 50 Hz., 1 Phase (input) 24 V AC (output)
• Cables: Marine Type
• Batteries : 2 x 200 A. Starter, 2 x 200 A. Service

Fire Fighting

• Fire Fighting Devices: Remote Controlled CO2 System in Engine Room
• 4 x 1 kg. At Cabin and Cockpit

Navigation

• Radar: JRC Scan Radar
• GPS: SIMRAD GPS (Plotter Chart) – CP 32
• Fluxgate Compass: SIMRAD – RFC 35 NMEA Compass

Communication

• Marine brand VHF: SAILOR – RT 2048 / D (DUBLEX & SIMPLEX)

Weapons

• Weapon Foundations: Telescopic at both sides at rear for M-60
